GmElementMesh Class Reference

Base interface for FEM (finite element) meshes. More...

#include <gmElementMesh.h>

Inheritance diagram for GmElementMesh:

Collaboration diagram for GmElementMesh:

Public Member Functions
	GmElementMesh (GmSimulationData *simulation, QString id, QString description, const GmLogCategory &logger)
	Standard constructor for element meshes.
virtual	~GmElementMesh ()
	Destructor.
const GmIntegrationRule *	elementIntegrationRule (GmCellType type, int ruleSet) const
	Returns the integration rule associated with the received element type / rule set.
const GmBorderIntegrationRule *	borderIntegrationRule (GmCellType type, int ruleSet, int borderIndex) const
	Returns the integration rule associated with a border (face for 3D elements or edge for 2D elements) of the received element type / rule set.
const GmBorderIntegrationRule *	faceIntegrationRule (GmCellType type, int ruleSet, int faceIndex) const
	Returns the integration rule associated with an element face of the received element type / rule set. This function is undefined for line or 2D elements.
const GmBorderIntegrationRule *	edgeIntegrationRule (GmCellType type, int ruleSet) const
	Returns the integration rule associated with an element edge of the received element type / rule set. This function is undefined for line elements.
int	maxNumIntPoints (int ruleSet) const
	Returns the maximum number of integration points used by a mesh element under the given rule set.
void	addIntegrationRuleSet ()
	Adds a new integration rule set to the mesh. Values are(conceptually) initialized to the element default rule.
int	numIntegrationRuleSets () const
	Returns the number of integration rule sets stored by this mesh.
bool	setElementIntegrationRule (GmCellType type, GmIntegrationRule *rule, int ruleSet)
	Allows the user to exchange the default integration rule tied to an element type / rule set.
bool	setFaceIntegrationRule (GmCellType type, GmBorderIntegrationRule *rule, int ruleSet, int faceType)
	Allows the user to exchange the default integration rule tied to a face of an element type. Please, see additional comments on setElementIntegrationRule()
bool	setEdgeIntegrationRule (GmCellType type, GmBorderIntegrationRule *rule, int ruleSet)
	Allows the user to exchange the default integration rule tied to an edge of an element type. Please, see additional comments on setElementIntegrationRule()
GmMeshGaussIndex *	gaussIndex (int ruleSet) const
	Returns the index object associated with the given rule set. The index is created on the first call to this function for the given rule set. Returns NULL if the index could not be created.
bool	usesGaussIndex (int ruleSet) const
	Returns true if the GaussIndex for the given rule set WAS already created by a call to gaussIndex(). Can only be called from the main thread since this question is not possible to answer in a multi-threaded scenario.
GmGaussValueSetGroup *	gaussValueSetGroup (int ruleSet) const
	Returns the ValueSetGroup object used to store the set of mesh Gauss value sets for attributes tied to given rule set. This is a very specialized function. Use only if you know what you are doing...
GmGaussValueSet *	gaussValueSet (QString id) const
	Returns the value set associated with the given Gauss attribute, NULL if not found. See comments for gaussValueSetGroup()
virtual QStringList	gaussAttributeIds () const
	Returns a list with the id names for every gauss attribute associated with mesh elments. No special order is enforced.
virtual GmValueInfo *	gaussAttributeInfo (QString id) const
	Returns the metadata describing the Gauss attribute named id.
virtual GmGaussAccessor *	gaussAttributeAccessor (QString id, Unit desiredUnit, const GmLogCategory &logger) const
	Creates an accessor object for the Gauss attribute named id.
virtual GmGaussAccessor *	gaussAttributeAccessor (QString id, int snum, bool locked, Unit desiredUnit, const GmLogCategory &logger) const
	Overloads gaussAttributeAccessor(QString, Unit, ...) to return an accessor for the requested previous state of a value.
virtual bool	addGaussAttributeSet (GmValueInfo *info)
	Creates a new value set for storing data associated with the Gauss attribute whose metadata information was received as a parameter.
virtual void	removeGaussAttributeSet (QString id)
	Removes gauss attribute set associated to the specified id. Do nothing if such gauss attribute set is not stored in the mesh.
virtual bool	initGaussAttributeSets ()
	Initializes all the value set groups after the addition of Gauss attributes by calls to addGaussAttributeSet(). MUST be called even if the mesh initially does not have any Gauss attribute.
virtual void	beginAddingGaussAttributeSets ()
	Initializes a block where calls to addGaussAttributeSet() will only initialize the new attribute value set at the call to endAddingGaussAttributeSets(). See the comments at addGaussAttributeSet(). Only makes sense after mesh initialization.
virtual bool	endAddingGaussAttributeSets ()
	Ends the block started by the call to beginAddingGaussAttributeSets(), initializing all the value sets that where added in between. See the comments at addGaussAttributeSet(). Returns false in case of errors.
virtual void	clearGaussAttributeSets ()
	An auxiliary function used to remove every Gauss valueSet stored in the mesh. Handy for plugins to cleanup on errors.
virtual void	clearGaussAttributeSetsData ()
	An auxiliary function used to remove all data from every Gauss valueSet stored in the mesh (the value sets themselves remain).
virtual bool	saveState (GmValueSet::SaveStateMode mode, const GmLogCategory &logger)
	Simmilar to saveNodeValueState(), saveCellValueState() and saveGaussAttributeState(), saves the current state of all nodal and cell values that support state saving. See saveNodeValueState(), saveCellValueState() and saveGaussAttributeState for more details.
virtual bool	saveGaussAttributeState (QString id, GmValueSet::SaveStateMode mode, const GmLogCategory &logger)
	Saves the current state for the requested id, creating a new current state.
virtual int	numGaussAttributeStates (QString id) const
	Returns the number of existing states for the requested id or -1 if the id doesn't exists.
virtual QString	gaussAttributeStateTag (QString id, int snum) const
	Returns the state tag attached to the requested state of the named value or "" if the id doesn't exists.
virtual double	gaussAttributeStateTime (QString id, int snum) const
	Returns the time tag attached to the requested state of the named value or -1 if the id doesn't exists.
virtual void	setGaussAttributeStateTag (QString id, int snum, QString tag)
	Sets a tag name for the requested state of the named value. Does nothing if the id doesn't exists.
virtual void	setGaussAttributeStateTime (QString id, int snum, double time)
	Sets a time tag for the requested state of the named value. Does nothing if the id doesn't exists.
virtual int	hPOrder () const
	Returns the elements P order for hierarchical meshes, 0 for meshes with conventional elements.
virtual int	hQOrder () const
	Returns the elements Q order for hierarchical meshes, 0 for meshes with conventional elements.
virtual void	printParameters (const GmLogCategory &logger)
	Reimplements the standard CellMesh::printParameters() method to add information about element integration rules.
virtual void	printValues (const GmLogCategory &logger, int options=GM_PRINT_DEFAULT)
	Reimplements the standard CellMesh::printValues() method to add information about gauss attributes.
virtual size_t	gaussIndicesMemory () const
	Returns the approximate memory used for storing Gauss indices.
Public Member Functions inherited from GmCellMesh
	GmCellMesh (GmSimulationData *simulation, QString id, QString description, const GmLogCategory &logger)
	Constructor.
virtual	~GmCellMesh ()
	Virtual destructor.
virtual int	numCells () const =0
	Returns the number of cells in the mesh.
virtual int	numActiveCells () const =0
	Returns the number of active cells in the mesh.
virtual int	numGlobalCells () const
	When working with partitioned meshes, returns the number of cells in the global mesh, before partitioning.
virtual const GmCell *	cell (int cellIndex) const =0
	Returns a cell of the mesh.
virtual GmCell *	cell (int cellIndex)=0
	Non const version of cell() const.
virtual const GmCellMeshTopology *	topology (bool create=true) const
	If the mesh supports the topology capability (hasCapability("topology") returns true), returns the mesh topology object that should be used for such queries. If there is no support, returns NULL.
virtual void	clearTopology ()
	If the mesh supports the topology capability (hasCapability("topology") returns true), suggests to the mesh that the topology information will not be needed anymore and so can be discarded (if at all possible depending on the plugin implementation).
virtual bool	hasSolidElements () const =0
	Returns true if the mesh includes solid elements. Notice that this is different from checking if node coordinates are 2D or 3D due to the possibility of a surface mesh with 3D coordinates (quad3d4 elements, for example)
virtual const int *	numCellTypes () const =0
	Returns a const vector of size equal to GM_NUM_CELL_TYPES where each entry is the number of cells of that type present in the mesh.
virtual const int *	numActiveCellTypes () const =0
	Returns a const vector of size equal to GM_NUM_CELL_TYPES where each entry is the number of active cells of that type present in the mesh.
virtual int	maxNumCellNodes () const =0
	Returns the maximum number of nodes in a mesh cell (equivalent to calculating the maximum of the number of nodes of each type that has a non zero entry in the vector returned by numCellTypes())
virtual int	maxNumCellGhostNodes () const
	Returns the maximum number of ghost nodes in a mesh cell.
virtual int	maxTotalNumCellNodes () const
	Returns the maximum total number of nodes (normal + ghost) in a cell mesh.
virtual void	ghostNodesUpdated (int nghost, int ntotal)
	Informs the mesh that the number of ghost nodes / total num nodes in a cell was updated to the given values, so that the mesh can update its statistics returned by maxNumCellGhostNodes() and maxTotalNumCellNodes().
virtual void	activeCellUpdated (GmCellType type, bool active)=0
	Informs the mesh that a cell had its active state changed, being made active / inactive. Called by GmCell::setactive()
virtual bool	isValid (QMap< int, int > &nonValidIds, bool valNonPlanar=false, bool print=true, double tol=1e-3) const
	Returns true if all the mesh cells are valid. Fill the non-valid cell ids if required.
virtual bool	isQualityGT (double minQuality) const
virtual void	qualityHistogram (QVector< int > &hist, int nbins=10) const
virtual double	edgeMinLength ()
virtual double	edgeMaxLength ()
virtual double	cellBboxMinLength ()
virtual double	cellBboxMaxLength ()
void	clearCellStatistics ()
	Clears cell statistics returned by edgeMaxLength() function and friends forcing its recalculation on next usage.
void	printQualityHistogram (bool activeOnly=true) const
	Prints cells quality histogram. If activeOnly is true, only the active cells will be scanned, all of them otherwise. Default = true.
virtual QStringList	cellGroupIds () const
	Returns a list with the names of the available cell groups.
virtual int	numCellsInGroup (int groupIndex) const
	Returns the number of cells present in the group referenced by groupIndex.
virtual const GmCell *	cellInGroup (int groupIndex, int cellIndex) const
	Returns a cell present in the group referenced by groupIndex.
virtual GmCell *	cellInGroup (int groupIndex, int cellIndex)
	Non const version of cellInGroup() const.
virtual const QMap< QString, GmCellBoundary * > &	cellBoundaryGroups () const =0
	Returns a map of boundaries registered within the mesh. Each entry in the returned map contains a group of cell edges or a group of cell faces that together define a boundary, indexed by group name.
virtual const QList< GmPropertySet * > &	propertySets () const =0
	Returns a reference to the list of property sets associated to this mesh.
virtual int	propertySetIndex (QString id) const =0
virtual GmValueInfo *	cellPropertyInfo (QString id) const
	Returns the metadata of the property named by id.
virtual GmCellAccessor *	cellPropertyAccessor (QString id, Unit desiredUnit, const GmLogCategory &logger) const
	Returns an accessor object for the property named by id.
virtual QStringList	cellValueIds (int filter=-1) const
	Returns a list with the id names for every attribute or state var associated with mesh cell, depending on the filter parameter. No special order is enforced. If filter is -1, includes both of them, first state vars and then cell attributes since that is the order used by printing routines.
virtual GmValueInfo *	cellValueInfo (QString id, int filter=-1) const
	Returns the metadata describing the cell values (attribute / state var) associated with the named id.
virtual GmCellAccessor *	cellValueAccessor (QString id, Unit desiredUnit, const GmLogCategory &logger) const
	Creates an accessor object for the cell attribute named id.
virtual GmCellAccessor *	cellValueAccessor (QString id, int snum, bool locked, Unit desiredUnit, const GmLogCategory &logger) const
	Overloads cellValueAccessor(QString, Unit, ...) to return an accessor for the requested previous state of a value.
virtual GmCellAccessor *	cellStateVarAccessorFromDof (int dof, Unit desiredUnit, GmStateVar **stateVar) const
	Creates an accessor object for the state var associated with the requested degree of freedom number. Returns NULL if the dof number is invalid or if that cell state var is not associated with this mesh.
virtual int	addCells (int *numCellTypes)
	Adds new cells to the mesh, WHITHOUT initializing their nodes or attributes.
virtual QList< int >	addedCells () const
	If the mesh supports mesh edition (hasCapability("addCells") returns true), this function should return a list with cell identifiers added to the mesh by calls to addCells() since the mesh creation or since the last call to clearAddedCells()
virtual void	clearAddedCells ()
	Method called by the assembler to clear the internal list used to track added cells. See comments on addedCells().
virtual int	addCellGroup (QString groupName)
	Adds a new (empty) cell group to the mesh.
virtual bool	addCellsToGroup (int groupId, const QVector< int > &cellIds)
	Adds the set of cells in the given list to the cell group. Assumes that the intersection of the given list with the current group cells is empty.
virtual bool	addCellsToGroup (int groupId, const QVector< QPair< int, int > > &cellIds)
	Adds the set of cells in the given list to the cell group.. The set of added cells is given by a vector with cell ranges. Each pair entry contains the cell index for the first and last cell in the range. Assumes that there is no intersection among the ranges and that the intersection of the given ranges with the current group cells is empty.
virtual bool	addCellValueSet (GmValueInfo *info)
	Creates a new value set for storing data associated with the attribute whose metadata information was received as a parameter.
virtual void	removeCellValueSet (QString id)
	Removes cell attribute set associated to the specified id. Do nothing if such cell attribute set is not stored in the mesh.
virtual bool	initCellValueSets ()
	Initializes all the value set groups after the addition of cell attributes by calls to addCellValueSet(). MUST be called even if the mesh initially does not have any cell attribute, AFTER the number of mesh cells has been correctly initialized!
virtual void	beginAddingCellValueSets ()
	Initializes a block where calls to addCellValueSet() will only initialize the new attribute value set at the call to endAddingCellValueSets(). See the comments at addCellValueSet(). Only makes sense after mesh initialization.
virtual bool	endAddingCellValueSets ()
	Ends the block started by the call to beginAddingCellValueSets(), initializing all the value sets that where added in between. See the comments at addCellValueSet(). Returns false in case of errors.
virtual void	clearCellValueSets ()
	An auxiliary function used to remove every valueSet stored in the mesh. Handy for plugins to cleanup on errors.
virtual void	clearCellValueSetsData ()
	An auxiliary function used to remove all data from every valueSet stored in the mesh (the value sets themselves remain).
virtual bool	saveCellValueState (QString id, GmValueSet::SaveStateMode mode, const GmLogCategory &logger)
	Saves the current state for the requested id, creating a new current state.
virtual int	numCellValueStates (QString id) const
	Returns the number of existing states for the requested id or -1 if the id doesn't exists.
virtual QString	cellValueStateTag (QString id, int snum) const
	Returns the state tag attached to the requested state of the named value or "" if the id doesn't exists.
virtual double	cellValueStateTime (QString id, int snum) const
	Returns the time tag attached to the requested state of the named value or -1 if the id doesn't exists.
virtual void	setCellValueStateTag (QString id, int snum, QString tag)
	Sets a tag name for the requested state of the named value. Does nothing if the id doesn't exists.
virtual void	setCellValueStateTime (QString id, int snum, double time)
	Sets a time tag for the requested state of the named value. Does nothing if the id doesn't exists.
virtual size_t	cellMemory () const =0
	Returns the approximate memory used for storing mesh cells (does not include memory for attributes)
virtual size_t	cellGroupsMemory () const =0
	Returns the approximate memory used for storing cell groups.
virtual size_t	cellBoundariesMemory () const =0
	Returns the approximate memory used for storing cell boundaries.
GmValueSetGroup *	cellValueSetGroup () const
	Returns the ValueSetGroup object used to store the set of mesh cell value sets. This is a very specialized function. Use only if you know what you are doing...
GmValueSet *	cellValueSet (QString id) const
	Returns the value set associated with the given cell attribute.
const GmCellGroupSet *	cellGroupSet (const QList< int > &groupIdList, bool disjoint)
	Auxiliar function used to manage cell group sets attached to the mesh.
const QVector< GmCellGroupSet * > &	cellGroupSets () const
	Returns the list of stored cell group set objects.
void	clearCellGroupSetsData (bool keepMeshSet)
	An auxiliary function used to remove all cell groups stored in the mesh.
Public Member Functions inherited from GmMesh
	GmMesh (GmSimulationData *simulation, QString id, QString description, const GmLogCategory &logger)
	Constructor.
virtual	~GmMesh ()
	Virtual destructor.
virtual const char *	pluginCategory () const
	Returns the plugin category.
virtual bool	hasCapability (QString capabilityName) const =0
	This function should return true or false to indicate whether the mesh implementation supports the requested capability or not. Capabilities are refered by string names in order to enable derived interfaces to extend the available capabilities that can be queried.
virtual bool	useDualVectors () const =0
	Returns true if the mesh data is stored in a "dual" vector, instead of a single one.
virtual void	pushProxy (lua_State *L, const GmLogCategory &logger)=0
	Pushes a proxy object for the current mesh onto the Lua stack.
virtual GmValueInfo *	nodeCoordInfo () const =0
	Returns metadata with information about node coordinates.
virtual GmValueAccessor *	nodeCoordAccessor (Unit desiredUnit, const GmLogCategory &logger) const =0
	Returns an accessor object used to access node coordinates.
virtual int	numNodes () const =0
	Returns the number of nodes in the mesh.
virtual int	numGhostNodes () const
	Returns the number of ghost nodes in the mesh.
int	totalNumNodes () const
	Returns the total number of nodes in the mesh, including normal nodes & ghost nodes.
virtual int	numGlobalNodes () const
	When working with partitioned meshes, returns the number of nodes in the global mesh, before partitioning.
virtual int	numGlobalGhostNodes () const
	When working with partitioned meshes, returns the number of ghost nodes in the global mesh, before partitioning.
int	totalNumGlobalNodes () const
	Returns the total number of nodes in the mesh, including normal nodes & ghost nodes.
int	toLinearGhostIndex (int nodeIndex) const
	If nodeIndex is a value with its high bit set, returns the index (high bit cleared)
int	toLocalGhostIndex (int nodeIndex) const
	Given a global ghost index (a value >= numNodes() and < totalNumNodes()), returns a zero based version of the index. If index is a 'geometry index' (nodeIndex < numNodes()), returns a negative value.
virtual const QMap< QString, GmNodeSet * > &	nodeSets () const =0
	Returns a map of node sets registered within the mesh. Each entry in the returned map contains a group of nodes, indexed by group name.
QStringList	nodeValueIds (int filter=-1) const
	Returns a list with the id names for every attribute or state var associated with mesh nodes, depending on the filter parameter. No special order is enforced. If filter is -1, includes both of them, first state vars and then node attributes since that is the order used by printing routines.
virtual GmValueInfo *	nodeValueInfo (QString id, int filter=-1) const
	Returns the metadata describing the values (attribute / state var) associated with the value id.
virtual GmValueAccessor *	nodeValueAccessor (QString id, Unit desiredUnit, const GmLogCategory &logger) const
	Creates an accessor object for the values (attribute / state var) associated with the value id.
virtual GmValueAccessor *	nodeValueAccessor (QString id, int snum, bool locked, Unit desiredUnit, const GmLogCategory &logger) const
	Overloads nodeValueAccessor(QString, Unit, ...) to return an accessor for the requested previous state of a value.
virtual GmValueAccessor *	nodeStateVarAccessorFromDof (int dof, Unit desiredUnit, GmStateVar **stateVar) const
	Creates an accessor object for the state var associated with the requested degree of freedom number. Returns NULL if the dof number is invalid or if that state var is not associated with this mesh.
virtual bool	addNodeValueSet (GmValueInfo *info)
	Creates a new value set for storing data associated with the metadata information received as a parameter.
virtual void	removeNodeValueSet (QString id)
	Removes node value set associated to the specified id. Do nothing if such node value set is not stored in the mesh.
virtual bool	initNodeValueSets ()
	Initializes all the value set groups after the addition of node attributes by calls to addNodeValueSet(). MUST be called even if the mesh initially does not have any node attribute / stat var, AFTER the number of mesh nodes and ghost nodes has been correctky initialized!
virtual void	beginAddingNodeAttributeSets ()
	Initializes a block where calls to addNodeValueSet() will only initialize the new attribute value set at the call to endAddingGaussAttributeSets(). See the comments at addNodeValueSet(). Only makes sense after mesh initialization.
virtual bool	endAddingNodeAttributeSets ()
	Ends the block started by the call to beginAddingGaussAttributeSets(), initializing all the value sets that where added in between. See the comments at addNodeValueSet(). Returns false in case of errors.
virtual void	clearNodeValueSets ()
	Removes every valueSet stored in the mesh (attributes and state variables). Handy for plugins to cleanup on errors.
virtual void	clearNodeValueSetsData ()
	An auxiliary function used to remove all data from every valueSet stored in the mesh (the value sets themselves remain).
virtual bool	saveNodeValueState (QString id, GmValueSet::SaveStateMode mode, const GmLogCategory &logger)
	Saves the current state for the requested id, creating a new current state.
virtual int	numNodeValueStates (QString id) const
	Returns the number of existing states for the requested id or -1 if the id doesn't exists.
virtual QString	nodeValueStateTag (QString id, int snum) const
	Returns the state tag attached to the requested state of the named value or "" if the id doesn't exists.
virtual double	nodeValueStateTime (QString id, int snum) const
	Returns the time tag attached to the requested state of the named value or -1 if the id doesn't exists.
virtual void	setNodeValueStateTag (QString id, int snum, QString tag)
	Sets a tag name for the requested state of the named value. Does nothing if the id doesn't exists.
virtual void	setNodeValueStateTime (QString id, int snum, double time)
	Sets a time tag for the requested state of the named value. Does nothing if the id doesn't exists.
virtual int	addNodes (int numNodes)
	Adds numNodes to the mesh, WHITHOUT initializing their coordinates or attributes.
virtual int	addGhostNodes (int numNodes)
	Similar to addNodes, this function adds ghost nodes to the mesh, WHITHOUT initializing their coordinates or attributes. This function should be reimplemented by mesh implementations that support ghost nodes (hasCapability("ghostNodes") returns true).
virtual void	clear ()
	Clears mesh nodes (and cells + other mesh related information depending on the concrete mesh type) if the mesh supports this operation (hasCapability("clear") returns true).
QMap< QString, GmPhysicsUserFunctions * > &	userFunctionsObjMap () const
	Returns the mesh map storing physics user function objects.
virtual size_t	nodeMemory () const =0
	Returns the approximate memory used for storing mesh nodes (does not include memory for s.v./attributes)
virtual size_t	nodeSetsMemory () const =0
	Returns the approximate memory used for storing node sets.
virtual GmPCR *	pcrObject () const =0
	Returns the PCR(Partition - Color - Renumber) object associated with this mesh. Should NEVER return NULL. If no PCR plugin object has been explicitely associated with the mesh by the user, or implicitely associated by default configuration options, a default object with no partition, coloring or renumbering MUST be returned. This default object is useful to keep code simple, without unnecessary conditions.
GmValueSetGroup *	nodeValueSetGroup () const
	Returns the ValueSetGroup object used to store the set of mesh node value sets. This is a very specialized function. Use only if you know what you are doing...
GmValueSet *	nodeValueSet (QString id) const
	Returns the node value set associated with the given cell attribute. Might be NULL. See comments for nodeValueSetGroup()
GmValueSetGroup *	ghostNodeValueSetGroup () const
	Returns the ValueSetGroup object used to store the set of mesh ghost node value sets. This is a very specialized function. Use only if you know what you are doing...
GmValueSet *	ghostNodeValueSet (QString id) const
	Returns the ghost node value set associated with the given cell attribute. Might be NULL. See comments for ghostNodeValueSetGroup()
virtual void	emitMeshChanged ()
	Emmits the signal meshChanged to signal other objects that the mesh has changed. Should be called by other processes after editions to the mesh like adding new nodes / cells or changing cell geometry.
Public Member Functions inherited from QObject
virtual const QMetaObject *	metaObject () const const
	QObject (QObject *parent)
virtual bool	event (QEvent *e)
virtual bool	eventFilter (QObject *watched, QEvent *event)
QString	objectName () const const
void	setObjectName (const QString &name)
bool	isWidgetType () const const
bool	isWindowType () const const
bool	signalsBlocked () const const
bool	blockSignals (bool block)
QThread *	thread () const const
void	moveToThread (QThread *targetThread)
int	startTimer (int interval, Qt::TimerType timerType)
int	startTimer (std::chrono::milliseconds time, Qt::TimerType timerType)
void	killTimer (int id)
T	findChild (const QString &name, Qt::FindChildOptions options) const const
QList< T >	findChildren (const QString &name, Qt::FindChildOptions options) const const
QList< T >	findChildren (const QRegExp &regExp, Qt::FindChildOptions options) const const
QList< T >	findChildren (const QRegularExpression &re, Qt::FindChildOptions options) const const
const QObjectList &	children () const const
void	setParent (QObject *parent)
void	installEventFilter (QObject *filterObj)
void	removeEventFilter (QObject *obj)
QMetaObject::Connection	connect (const QObject *sender, const char *signal, const char *method, Qt::ConnectionType type) const const
bool	disconnect (const char *signal, const QObject *receiver, const char *method) const const
bool	disconnect (const QObject *receiver, const char *method) const const
void	dumpObjectTree ()
void	dumpObjectInfo ()
void	dumpObjectTree () const const
void	dumpObjectInfo () const const
bool	setProperty (const char *name, const QVariant &value)
QVariant	property (const char *name) const const
QList< QByteArray >	dynamicPropertyNames () const const
void	destroyed (QObject *obj)
void	objectNameChanged (const QString &objectName)
QObject *	parent () const const
bool	inherits (const char *className) const const
void	deleteLater ()
	Q_DISABLE_COPY (Class)
	Q_DISABLE_MOVE (Class)
	Q_DISABLE_COPY_MOVE (Class)
T	qobject_cast (QObject *object)
T	qobject_cast (const QObject *object)
T	qFindChild (const QObject *obj, const QString &name)
QList< T >	qFindChildren (const QObject *obj, const QString &name)
QList< T >	qFindChildren (const QObject *obj, const QRegExp &regExp)
	Q_CLASSINFO (Name, Value)
	Q_INTERFACES (...)
	Q_PROPERTY (...)
	Q_ENUMS (...)
	Q_FLAGS (...)
	Q_ENUM (...)
	Q_FLAG (...)
	Q_ENUM_NS (...)
	Q_FLAG_NS (...)
	Q_OBJECT Q_OBJECT
	Q_GADGET Q_GADGET
	Q_NAMESPACE Q_NAMESPACE
	Q_NAMESPACE_EXPORT (EXPORT_MACRO)
	Q_SIGNALS Q_SIGNALS
	Q_SIGNAL Q_SIGNAL
	Q_SLOTS Q_SLOTS
	Q_SLOT Q_SLOT
	Q_EMIT Q_EMIT
	Q_INVOKABLE Q_INVOKABLE
	Q_REVISION Q_REVISION
	Q_SET_OBJECT_NAME (Object)
	QT_NO_NARROWING_CONVERSIONS_IN_CONNECT QT_NO_NARROWING_CONVERSIONS_IN_CONNECT
Public Member Functions inherited from GmPluginObject
	GmPluginObject (GmSimulationData *simulation, QString id, QString description, const GmLogCategory &logger)
	Constructor.
virtual	~GmPluginObject ()
	Destructor.
QString	id () const
	Returns the object id.
QString	description () const
	Returns the object description.
QString	pluginTypeName () const
	Returns the hierarchical type name for the plugin object type. See also pluginName() and pluginType().
virtual const char *	pluginName () const =0
	Returns a string identifying the plugin which implements this object. Should return the SAME string as the one read from the plugin information file in the pluginName field.
virtual const char *	pluginType () const =0
	Returns the string identifying the plugin object type. Should return the SAME string as the one read from the plugin information file in the objectTypes table.
virtual bool	loadPrivateData (LuaTable &table)=0
	Function called by the model loader to give the object acess to it's private parameters. Should return false only if the received parameter set makes the use of this object impossible.
Public Member Functions inherited from GmGroupDumpItem
virtual	~GmGroupDumpItem ()
	Virtual destructor.
virtual bool	stateAboutToBeSaved (GmStateDump *state)
	Virtual method called just before starting a save operation on the given state. Returning false aborts the operation.
virtual bool	stateSaved (GmStateDump *state)
	Virtual method called just after succesfully completing a save operation on the given state. Returning false aborts the operation.
virtual bool	stateAboutToBeLoaded (GmStateDump *state)
	Virtual method called just before starting a load operation on the given state. Returning false aborts the operation.
virtual bool	stateLoaded (GmStateDump *state)
	Virtual method called just after succesfully completing a load operation on the given state. Returning false aborts the operation.

Protected Member Functions
virtual GmGaussValueSetGroup *	createGaussValueSetGroup (GmSimulationData *simulation, GmElementMesh *mesh)
	Virtual function responsible for creating a new GmGaussValueSetGroup that will store data for the attributes tied to a specific rule set. Can be replaced in derived classes to allow for other implementations for the class. This is particulary important for the XFem plugin.
template<class T >
T *	getIntegrationRuleWithDCL (QList< QAtomicPointer< T > * > &list, QMutex *mutex, T *(*instance)(GmCellType, int, int, int, GmIntegrationRuleType), GmCellType type, int ruleSet, int faceType) const
	Auxiliar function that uses the Double Checked Locking Pattern (DCLP) to grab an integration rule from the given list, creating it by calling instance() if the list doesn't already have an integration rule for the given type and rule set.
virtual bool	addStateAccessorData (GmStateDump *state, int groupId)
	Adds to 'state' accessors for all the Gauss attributes associated with this mesh. This includes all histories. (also adds node and cell attributes through the base class). Returns true on success or false on error.
virtual bool	fillDumpControlMapData (QVariantMap *map, const GmLogCategory &logger)
	Fills the dump control data map with mesh data prior to a save operation On errors, should return false and report the error through the provided state dump logger.
virtual bool	dumpControlMapDataLoaded (QVariantMap *map, const GmLogCategory &logger)
	Sanity checks + processing of the dump control data map after a load operation.
Protected Member Functions inherited from GmCellMesh
Protected Member Functions inherited from GmMesh
GmValueSet *	anyVsFromId (QString id) const
	Helper function that, given an id, returns the node value set for that id if it exists. Otherwise returns the ghost value set for that id(which may also be NULL for an invalid id).
void	printValueInfo (const GmLogCategory &logger, QString title, const QStringList &idList)
	Auxiliary function to print information about state variables or attributes.
virtual bool	addStateItemsToGroup (GmStateDump *state, int groupId)
	Adds to 'state' a data item storing a control map, followed by geometry data filled by addStateGeometryData(), followed by mesh attribute data filled by addStateAccessorData(). All the items are added to the given group. Returns true on success or false on error.
virtual int	controlMapStateItemType ()
	Virtual function that needs to be implemented by concrete implementation classes supporting the stateDump capability. It should return a dump type that identifies the mesh implementation.
virtual bool	addStateGeometryData (GmStateDump *state, int groupId)
	Virtual function that needs to be implemented by concrete implementation classes supporting the stateDump capability. It should add the needed additional items to the state. Keep in mind that some of the needed control data can be added/loaded from the control map, already added to the state by the standard implementation of addStateItemsToGroup(), through the fillDumpControlMapData() / dumpControlMapDataLoaded() pair of functions.
Protected Member Functions inherited from QObject
QObject *	sender () const const
int	senderSignalIndex () const const
int	receivers (const char *signal) const const
bool	isSignalConnected (const QMetaMethod &signal) const const
virtual void	timerEvent (QTimerEvent *event)
virtual void	childEvent (QChildEvent *event)
virtual void	customEvent (QEvent *event)
virtual void	connectNotify (const QMetaMethod &signal)
virtual void	disconnectNotify (const QMetaMethod &signal)
Protected Member Functions inherited from GmPluginObject
virtual const GmLogCategory &	logger () const
	Returns the internal logger used by the plugin to emmit messages.
GmSimulationData *	simulationData () const
	Returns a reference to the simulation data object keeping global simulation information.

Protected Attributes
QVector< GmGaussValueSetGroup * >	_gaussAttributesGroupList
	The per rule set value set group list, storing Gauss attributes data tied to each rule set.
QMap< QString, int >	_gaussAttributesMap
	For each attribute id, stores the result set that this attribute is associated with.
Protected Attributes inherited from GmMesh
int	_stateDumpControlMapItem
	The dump item index for the control map. Used to make sure that there are no mesh data accessors prior to the map on the state.

Private Member Functions
QString	toRuleStr (GmIntegrationRule *ir) const
	Returns a string containing the rule's cache key + its creation parameters.
bool	fromRuleStr (QString r, int *key, GmIntegrationRuleType *type, int *rule1, int *rule2, int *rule3)
	Splits the rule string created by toRuleStr() into its components.
void	clearRuleSetRules (int rule)
	Removes the vector and all integration rules from the given position on the rules lists.

Private Attributes
QList< QAtomicPointer< GmIntegrationRule > * >	_elemIntegrationRulesList
	List with sets of per element type integration rules.
QList< QAtomicPointer< GmBorderIntegrationRule > * >	_faceIntegrationRulesList
	List with sets of per element type face integration rules.
QList< QAtomicPointer< GmBorderIntegrationRule > * >	_edgeIntegrationRulesList
	List with sets of per element type edge integration rules.
QMutex	_elemIntegrationRulesMutex
	The mutex protecting _elemIntegrationRulesList.
QMutex	_faceIntegrationRulesMutex
	The mutex protecting _faceIntegrationRulesList.
QMutex	_edgeIntegrationRulesMutex
	The mutex protecting _edgeIntegrationRulesList.
QVector< QAtomicPointer< GmMeshGaussIndex > >	_gaussIndexList
	List of per integration rule set Gauss index.
QMutex	_gaussIndexMutex
	The mutex protecting _gaussIndexList.

Additional Inherited Members
Public Types inherited from QObject
typedef	QObjectList
Signals inherited from GmMesh
void	meshChanged ()
	Signal emmited by emitMeshChanged(). See comments on that function.
Static Public Member Functions inherited from GmMesh
static bool	isGhostNode (int nodeIndex)
	Returns true if the given index is a ghost node index, false if not.
static int	setGhostFlag (int nodeIndex)
	Returns the given index with the ghost node bit set.
static int	clearGhostFlag (int nodeIndex)
	Returns the given index with the ghost node bit cleared.
Static Public Member Functions inherited from QObject
QString	tr (const char *sourceText, const char *disambiguation, int n)
QString	trUtf8 (const char *sourceText, const char *disambiguation, int n)
QMetaObject::Connection	connect (const QObject *sender, const char *signal, const QObject *receiver, const char *method, Qt::ConnectionType type)
QMetaObject::Connection	connect (const QObject *sender, const QMetaMethod &signal, const QObject *receiver, const QMetaMethod &method, Qt::ConnectionType type)
QMetaObject::Connection	connect (const QObject *sender, PointerToMemberFunction signal, const QObject *receiver, PointerToMemberFunction method, Qt::ConnectionType type)
QMetaObject::Connection	connect (const QObject *sender, PointerToMemberFunction signal, Functor functor)
QMetaObject::Connection	connect (const QObject *sender, PointerToMemberFunction signal, const QObject *context, Functor functor, Qt::ConnectionType type)
bool	disconnect (const QObject *sender, const char *signal, const QObject *receiver, const char *method)
bool	disconnect (const QObject *sender, const QMetaMethod &signal, const QObject *receiver, const QMetaMethod &method)
bool	disconnect (const QMetaObject::Connection &connection)
bool	disconnect (const QObject *sender, PointerToMemberFunction signal, const QObject *receiver, PointerToMemberFunction method)
Properties inherited from QObject
	objectName

Detailed Description

Base interface for FEM (finite element) meshes.

This interface basically adds methods related to FEM models.

Member Function Documentation

addGaussAttributeSet()

bool GmElementMesh::addGaussAttributeSet ( GmValueInfo * info )

virtual

Creates a new value set for storing data associated with the Gauss attribute whose metadata information was received as a parameter.

The new value set takes ownership of the info object. It should be noted that info MUST have kind equal to GM_GAUSS_ATTRIBUTE.

If this function is being called during mesh loading / initialization, the added attribute will only be available for value filling through an accessor after the call to initGaussAttributeSets().

When called after attribute initialization, the new attribute will be imediately initialized with the correct size for its associated rule set, and will be ready for filling, unless the call is inside a beginAddingGaussAttributeSets() / endAddingGaussAttributeSets() call block. In that later case, the new attribute size initialization is delayed untill the end call. This allows for the addition of several attributes to a new or existing "interleaved pack" in a much more efficient way and is necessary, for example, for the addition of new Gauss result attributes inside a single packed group by the physics plugin.

The function returns false in case of errors (memory could not be allocated, or the mesh already has a Gauss attribute with the requested id, for example).
In that case, info is NOT deallocated by addGaussAttributeSet().

addIntegrationRuleSet()

void GmElementMesh::addIntegrationRuleSet

(

)

Adds a new integration rule set to the mesh. Values are(conceptually) initialized to the element default rule.

  IMPORTANT: The new GaussValueSetGroup object used to store attributes tied to this new rule set is created
  with the aid of the createGaussValueSetGroup() virtual function. It can be overwritten in derived classes
  as needed. If mesh value set groups are already initialized, the new group will also be initialized.

addStateAccessorData()

bool GmElementMesh::addStateAccessorData ( GmStateDump * state, int groupId )

protectedvirtual

Adds to 'state' accessors for all the Gauss attributes associated with this mesh. This includes all histories. (also adds node and cell attributes through the base class). Returns true on success or false on error.

Reimplemented from GmCellMesh.

borderIntegrationRule()

const GmBorderIntegrationRule * GmElementMesh::borderIntegrationRule	(	GmCellType	type,
		int	ruleSet,
		int	borderIndex ) const

Returns the integration rule associated with a border (face for 3D elements or edge for 2D elements) of the received element type / rule set.

For 2D elements it is equivalent to edgeIntegrationRule() and for 3D elements to faceIntegrationRule(). This function is undefined for line elements. It can be used for building generic code that works for both 2D and 3D elements.

The border index parameter is used only if type is a 3D element with more than one face type (like a wedge). In that case, it should be the face index for the integration face and will be used to choose the correct face rule to be used. Otherwise, any valid face / edge index can be used (like 0).

dumpControlMapDataLoaded()

bool GmElementMesh::dumpControlMapDataLoaded ( QVariantMap * map, const GmLogCategory & logger )

protectedvirtual

Sanity checks + processing of the dump control data map after a load operation.

Reimplemented from GmCellMesh.

faceIntegrationRule()

const GmBorderIntegrationRule * GmElementMesh::faceIntegrationRule	(	GmCellType	type,
		int	ruleSet,
		int	faceIndex ) const

Returns the integration rule associated with an element face of the received element type / rule set. This function is undefined for line or 2D elements.

The face index parameter is used only if type has more than one face type (like a wedge). In that case, it should be the face index for the integration face and will be used to choose the correct face rule to be used. Otherwise, any valid face index can be used (like 0).

fillDumpControlMapData()

bool GmElementMesh::fillDumpControlMapData ( QVariantMap * map, const GmLogCategory & logger )

protectedvirtual

Fills the dump control data map with mesh data prior to a save operation On errors, should return false and report the error through the provided state dump logger.

Reimplemented from GmCellMesh.

gaussAttributeAccessor() [1/2]

GmGaussAccessor * GmElementMesh::gaussAttributeAccessor ( QString id, int snum, bool locked, Unit desiredUnit, const GmLogCategory & logger ) const

virtual

Overloads gaussAttributeAccessor(QString, Unit, ...) to return an accessor for the requested previous state of a value.

The snum parameter contains the requested state. A value of zero means the current state, 1 the previous one, 2 the one before that and so on. Valid values range from zero to the oldest state for the requested variable, which can be queried with a call to numGaussAttributeStates(). Remember that for a value accessor to support states, the history parameter must be set in its value info object.

The locked parameter controls the behaviour of the accessor once a new state is created for the value. The 'lock' refers to the state number, so if locked is false and a new state is created, the accessor doesn't change and continues to point to the same data. If locked is true, the accessor will be locked to that state number so when a new state is created, the accessor changes the data its looking upon to reflect the new satte. For example, an accessor locked on the state 0 will always point to the current state and one locked to the state 1 will always point to the previous saved value.

See the overloaded function for the remaining parameters.

gaussAttributeAccessor() [2/2]

GmGaussAccessor * GmElementMesh::gaussAttributeAccessor ( QString id, Unit desiredUnit, const GmLogCategory & logger ) const

virtual

Creates an accessor object for the Gauss attribute named id.

If the id does not refer to a known attribute, returns NULL.

If desiredUnit is a known unit, different from the basic attribute unit, the value will be automatically converted to the desired unit. If no conversion is possible, the function returns NULL. To avoid conversions, just pass Unit() as the desiredUnit.

The logger parameter exists to allow for the accessor to use a different logger than the mesh one to report errors. For example, in an analysis context it might be interesting to report errors through the physics plugin logger instead of by the mesh logger.

IMPORTANT: The returned accessor should be deallocated by the caller.

Obs: This is equivalent to calling gaussAttributeAccessor(id, 0, true, desiredUnit, logger)

gaussAttributeInfo()

GmValueInfo * GmElementMesh::gaussAttributeInfo ( QString id ) const

virtual

Returns the metadata describing the Gauss attribute named id.

If the id does not refer to a known attribute, returns NULL.

gaussIndex()

GmMeshGaussIndex * GmElementMesh::gaussIndex

(

int

ruleSet

)

const

Returns the index object associated with the given rule set. The index is created on the first call to this function for the given rule set. Returns NULL if the index could not be created.

The implementation uses the DCL pattern. See comments on getIntegrationRuleWithDCL() for additional information.

getIntegrationRuleWithDCL()

template<class T >

T * GmElementMesh::getIntegrationRuleWithDCL ( QList< QAtomicPointer< T > * > & list, QMutex * mutex, T *(* instance )(GmCellType, int, int, int, GmIntegrationRuleType), GmCellType type, int ruleSet, int faceType ) const

protected

Auxiliar function that uses the Double Checked Locking Pattern (DCLP) to grab an integration rule from the given list, creating it by calling instance() if the list doesn't already have an integration rule for the given type and rule set.

Using DCLP guranteees that all accesses but the first one have minimum overhead.

See https://preshing.com/20130930/double-checked-locking-is-fixed-in-cpp11/ for an extensive documentation about the DCLP problem.

The faceType parameter should be passed as 0 for non face lists.

printParameters()

void GmElementMesh::printParameters ( const GmLogCategory & logger )

virtual

Reimplements the standard CellMesh::printParameters() method to add information about element integration rules.

Reimplemented from GmCellMesh.

printValues()

void GmElementMesh::printValues ( const GmLogCategory & logger, int options = GM_PRINT_DEFAULT )

virtual

Reimplements the standard CellMesh::printValues() method to add information about gauss attributes.

Reimplemented from GmCellMesh.

saveGaussAttributeState()

bool GmElementMesh::saveGaussAttributeState ( QString id, GmValueSet::SaveStateMode mode, const GmLogCategory & logger )

virtual

Saves the current state for the requested id, creating a new current state.

If the value does not supports history values, does nothing, returning false. The mode parameter defines how the new state will be initialized (with a copy of the old one, with the value default or uninitialized).

The time associated with the new current state is initialized to the value of the current time as seen from the simulation data object. This can later be changed by a call to setGaussAttributeStateTime().

Returns true if the state was created successfully, false otherwise.

saveState()

bool GmElementMesh::saveState ( GmValueSet::SaveStateMode mode, const GmLogCategory & logger )

virtual

Simmilar to saveNodeValueState(), saveCellValueState() and saveGaussAttributeState(), saves the current state of all nodal and cell values that support state saving. See saveNodeValueState(), saveCellValueState() and saveGaussAttributeState for more details.

Reimplemented from GmCellMesh.

setElementIntegrationRule()

bool GmElementMesh::setElementIntegrationRule	(	GmCellType	type,
		GmIntegrationRule *	rule,
		int	ruleSet )

Allows the user to exchange the default integration rule tied to an element type / rule set.

Integration rules are tied to element types and not to elements in order to allow the element to be a lightweight object. Since in most scenarios all elements of a type will share an integration rule, we really don't need to store a pointer to an integration rule in each and every element.

Returns false if the rule is not compatible with the element type. Otherwise, returns true and takes the ownership of the integration rule that will be deleted by the mesh destructor.

Obs: If the per element type (and rule set) schema proves to be too stringent and we really need to have two elements of the same type, in the same rule set, with different integration rules a not so complicated solution would be to implement the concept of subtypes, associating rules with subtypes and not types anymore. Each type can have a (fixed) number of subtypes. This can be implemented rather efficiently if we use, for example 2 bits from element id numbers to store the subtype (which would give 4 subtypes and still let us have a mesh with 1G elements).

setFaceIntegrationRule()

bool GmElementMesh::setFaceIntegrationRule	(	GmCellType	type,
		GmBorderIntegrationRule *	rule,
		int	ruleSet,
		int	faceType )

Allows the user to exchange the default integration rule tied to a face of an element type. Please, see additional comments on setElementIntegrationRule()

The faceType parameter is used when the element type has faces with different types (wedge, for example). In this case, one different rule should be stored for each face type. For elements with a single face type, this parameter must be filled with the element's face type or with -1 (the type will be inferred from the element type).

---

The documentation for this class was generated from the following files:

• inc/model/gmElementMesh.h
• src/model/gmElementMesh.cpp
